技術參數 parameter |
|
鋸片****使用直徑 max diameter of saw |
1600mm |
工作臺車機動進給行程 working platform feed stroke |
5400mm |
|
****安裝鋸片數 max number of blade installation |
30 |
工作臺車面 dimensions of working platform |
5000x2260mm |
|
****橫向行程 max horizontal stroke |
3500mm |
****加工石板尺寸 max cutting size |
3200x600x30mm |
|
****升降行程 max up-down stroke |
1900mm |
****加工荒料尺寸 max processing blocks size |
3200x5000x1900mm |
|
主電機功率 main motor power |
110kw |
外形尺寸 overall size |
9600x16760x7385mm |
|
總功率 total power |
146.6kw |
整機重量 weight |
35000kg |
